HCG Dry drum magnetic separator in mining
2. Variable frequency drive (VFD) speed control increases throughput by up to 50%, adaptable to various mineral properties.
3. Special ceramic casing with high hardness, long lifespan, and significantly extended maintenance intervals.
4. Unique material distribution structure allows for flexible adjustment of concentrate and tailings grades, suitable for pre-enrichment of 0-12mm fine ores.
5. Dry separation eliminates the need for water; pre-selection and upgrading reduce subsequent energy consumption, making it environmentally friendly and energy-saving.
one.Product Introduction
two.Product Principle
The HCG Dry Drum Magnetic Separator in Mining is based on the principle of permanent magnet adsorption. The equipment has a semi-circular strong magnetic system inside the drum, forming a high-intensity magnetic field zone. When the material passes through the magnetic field zone, magnetic minerals are quickly adsorbed onto the drum surface and fall into the concentrate inlet under their own weight after the drum rotates to the non-magnetic zone; non-magnetic minerals directly enter the tailings inlet through the magnetic field, achieving precise separation.
three.Product Advantages
- HCG Dry Drum Magnetic Separator in Mining features a unique magnetic circuit structure, significantly improving concentrate grade.
- Effectively controls tailings runoff, resulting in high ore recovery rates.
- The frequency converter precisely controls the speed, increasing throughput by 50%.
- HCG Dry Drum Magnetic Separator in Mining adapts to different mineral properties, offering flexible operation.
- The drum surface uses special wear-resistant ceramics with a hardness of HRA≥85.
- Long service life and significantly extended maintenance cycles.
- HCG Dry Drum Magnetic Separation in Mining features a unique material distribution structure, allowing for flexible adjustment of concentrate and tailings grades.
- Suitable for pre-enrichment of 0-12mm fine ores, with a wide range of applications.
- HCG Dry Drum Magnetic Separation in Mining requires no water, reducing environmental impact.
- Pre-selection and upgrading reduce energy consumption in subsequent grinding and beneficiation.
four.Industry Applications
- Iron ore pre-concentration: pre-enrichment of ultra-low grade magnetite
- Mining development: economical and efficient utilization of low-grade ores
- Resource recovery: recycling of resources from tailings ponds
- Mineral processing: magnetic separation of various dry powder minerals
- Mineral processing upgrade: optimization and upgrading of existing mineral processing processes
FAQS
Are you a trading company or a factory?
Posted on
We are located in Shandong Province, China, with 200 employees and 2 workshops covering an area of 20000 square meters. Welcome to visit the factory anytime.
We are located in Shandong Province, China, with 200 employees and 2 workshops covering an area of 20000 square meters. Welcome to visit the factory anytime.
Do you provide sampling services?
Posted on
Yes, we provide free sample service. After receiving your sample, we will arrange mineral processing test and provide equipment solutions based on the data.
Yes, we provide free sample service. After receiving your sample, we will arrange mineral processing test and provide equipment solutions based on the data.
Is the product internationally certified?
Posted on
Yes, our equipment is fully certified and complies with market industry standards (such as CE, UL, ISO, etc.).
Yes, our equipment is fully certified and complies with market standards.
Can we produce customized products?
Posted on
Yes, our products can provide customized services, and our professional technicians will provide you with equipment drawings and solutions according to your requirements.
Yes, our products can provide customized services, and our professional technicians will provide you with equipment drawings and solutions according to your requirements.
How long is the warranty period for your products?
Posted on
The warranty period is 1 year, please consult sales for details. We will provide lifetime technical support services and provide spare parts at the lowest price.
The warranty period is 1 year, please consult sales for details. We will provide lifetime technical support services and provide spare parts at the lowest price.
How long is the production cycle?
Posted on
Normally it is about 15 to 30 days, unless there are special circumstances, it may take longer.
Normally it is about 15 to 30 days, unless there are special circumstances, it may take longer.
Learn about Hengci
Shandong Hengci Technology Co., Ltd. was established in 2015 with a registered capital of 22 million RMB. It is a professional manufacturer of magnetic separation equipment, including dry magnetic separators, wet magnetic separators, and iron removers (permanent magnetic and electromagnetic types). The company has 150 employees, holds 13 patents, and possesses qualifications such as high-tech enterprise certification.
